Jetpack compose: How to use TabRow

Jetpack Compose: How to Use TabRow

This code demonstrates how to create a basic tabbed interface using the TabRow composable in Jetpack Compose. It defines three composable functions: MainActivity, GetScaffold, and MainContent.

Breakdown:

MainActivity: This is the main activity class for the application. It sets the content of the activity using setContent composable and calls the GetScaffold function to define the UI.
GetScaffold: This composable defines the overall structure of the app using the Scaffold composable. It includes a TopAppBar with a title and background color, a scrollable content area defined by MainContent, and a background color for the entire scaffold.
MainContent: This composable handles the core functionality of the tabbed interface. It uses:
- remember: This is used to create a mutable state variable selectedIndex to track the currently selected tab index.
- tabs: This is a list containing the text labels for each tab.
- Column: This layout arranges its children vertically. Inside the column:
  - TabRow: This composable defines the row of tabs with properties for selectedTabIndex, backgroundColor, and contentColor. It iterates through the tabs list using forEachIndexed to create individual Tab composables.
    - Tab: This composable represents a single tab with properties for selected (based on selectedIndex), and onClick to handle tab selection changes. It displays the tab text inside a Text composable.
  - Box: This positions the content of the selected tab in the center of the remaining space. Inside the box:
    - Text: This displays the text of the currently selected tab with a larger font size.

Summary

This code provides a starting point for implementing tabbed interfaces in your Jetpack Compose applications. It demonstrates how to manage the selected tab state, create tab visuals, and display content based on the chosen tab. You can customize this example further by adding icons to the tabs, changing the tab behavior (e.g., making them scrollable), and styling them to match your app's design language.

MainActivity.kt


package com.cfsuman.jetpackcompose

import android.os.Bundle
import androidx.activity.ComponentActivity
import androidx.activity.compose.setContent
import androidx.compose.foundation.layout.*
import androidx.compose.material.*
import androidx.compose.runtime.*
import androidx.compose.ui.graphics.Color
import androidx.compose.material.Text
import androidx.compose.material.TopAppBar
import androidx.compose.ui.Alignment
import androidx.compose.ui.Modifier
import androidx.compose.ui.text.TextStyle
import androidx.compose.ui.unit.dp
import androidx.compose.ui.unit.sp


class MainActivity : ComponentActivity() {
    override fun onCreate(savedInstanceState: Bundle?) {
        super.onCreate(savedInstanceState)
        setContent {GetScaffold()}
    }


    @Composable
    fun GetScaffold() {
        Scaffold(
            topBar = {TopAppBar(
                title = {Text(text = "Compose - TabRow")},
                backgroundColor = Color(0xFF89CFF0),
            )},
            content = { MainContent() },
            backgroundColor = Color(0xFFF0FFFF)
        )
    }


    @Composable
    fun MainContent() {
        var selectedIndex by remember { mutableStateOf(0)}
        val tabs = listOf("Tab A","Tab B","Tab C","Tab D")

        Column(Modifier.fillMaxSize()) {
            TabRow(
                selectedTabIndex = selectedIndex,
                backgroundColor = Color(0xFF2E5894),
                contentColor = Color(0xFFBCD4E6)
            ) {
                tabs.forEachIndexed { index, tab ->
                    Tab(
                        selected = selectedIndex == index,
                        onClick = { selectedIndex = index},
                    ) {
                        Text(
                            text = tab,
                            modifier = Modifier.padding(12.dp)
                        )
                    }
                }
            }

            Box(Modifier.fillMaxSize().wrapContentSize(Alignment.Center)) {
                Text(
                    text = tabs[selectedIndex],
                    style = TextStyle(fontSize = 30.sp)
                )
            }
        }
    }
}
