MainActivity.kt
package com.cfsuman.kotlintutorials
import android.content.Context
import android.os.Bundle
import android.util.TypedValue
import android.widget.*
import androidx.appcompat.app.AppCompatActivity
import androidx.constraintlayout.widget.ConstraintLayout
import androidx.constraintlayout.widget.ConstraintSet
import androidx.constraintlayout.widget.ConstraintSet.*
class MainActivity : AppCompatActivity() {
private lateinit var context:MainActivity
override fun onCreate(savedInstanceState: Bundle?) {
super.onCreate(savedInstanceState)
setContentView(R.layout.activity_main)
// Get the context
context = this
// Get the widgets reference from XML layout
val rootLayout = findViewById<ConstraintLayout>(R.id.rootLayout)
val textView = findViewById<TextView>(R.id.textView)
val button = findViewById<Button>(R.id.button)
button.setOnClickListener {
val constraintSet = ConstraintSet()
constraintSet.clone(rootLayout)
// put the text view bottom of button widget with margin
constraintSet.connect(
textView.id, // text view to change constraint
TOP, // put text view top side bottom of button
button.id, // button to put text view bellow it
BOTTOM, // button bottom to put text view bellow it
24.toDp(context) // margin (optional)
)
// horizontally center align the text view
// text view constraint start to start of parent
constraintSet.connect(
textView.id,
START,
PARENT_ID,
START
)
// text view constraint end to end of parent
constraintSet.connect(
textView.id,
END,
PARENT_ID,
END
)
// finally, apply the constraint set to layout
constraintSet.applyTo(rootLayout)
}
}
}
// Extension method to convert dp to equivalent pixels
fun Int.toDp(context: Context):Int = TypedValue.applyDimension(
TypedValue.COMPLEX_UNIT_DIP,
this.toFloat(),
context.resources.displayMetrics
).toInt()
activity_main.xml
<?xml version="1.0" encoding="utf-8"?>
<androidx.constraintlayout.widget.ConstraintLayout
xmlns:android="http://schemas.android.com/apk/res/android"
xmlns:app="http://schemas.android.com/apk/res-auto"
android:layout_width="match_parent"
android:layout_height="match_parent"
android:id="@+id/rootLayout"
android:background="#DCDCDC"
android:padding="16dp">
<Button
android:id="@+id/button"
android:layout_width="wrap_content"
android:layout_height="wrap_content"
android:text="Set TextView Constraint"
app:layout_constraintEnd_toEndOf="parent"
app:layout_constraintStart_toStartOf="parent"
app:layout_constraintTop_toTopOf="parent" />
<TextView
android:id="@+id/textView"
android:layout_width="300dp"
android:layout_height="wrap_content"
android:background="#FEFEFA"
android:padding="12dp"
android:fontFamily="sans-serif"
android:textStyle="italic"
android:text="Lorem ipsum dolor sit amet, consectetur
adipiscing elit. In dapibus urna id mauris maximus,
at placerat nibh pretium. Donec ac mi orci.
Suspendisse potenti. Nulla id ultrices enim.
Phasellus leo velit, porttitor sit amet rhoncus
eu, molestie non risus."
android:textColor="#2E5894"
android:textSize="24sp" />
</androidx.constraintlayout.widget.ConstraintLayout>
